    High Accuracy Chrome Plated Steel Bar Neutral Salt Spray Test 500 Hours Hydraulic Cylinder

    Ask Lasest Price
    Brand Name : DALLAST APT
    Model Number : Model
    Certification : TUV SGS
    Payment Terms : T/T
    Supply Ability : 1000000pcs/year
    Delivery Time : 15-25 days
    • Product Details
    • Company Profile

    High Accuracy Chrome Plated Steel Bar Neutral Salt Spray Test 500 Hours Hydraulic Cylinder

    NSS1000 Hours 42CrMo4 Hollow Piston Rod Hard Chrome Plated Steel Bar For Hydraulic Cylinder


    Hollow/Solid Rod
    specificationφ3-φ12φ16-φ25φ30-φ50φ55-φ100φ105-φ120
    Length200-2000200-3000200-5000200-100001000-10000


    NSS
    (Neutral Salt Spray test)

    More than 240 hours ;
    more than 360 hours;
    more than 500 hours ;
    more than 100 hours;

    Surface hardness>860 HV0.1The straightness0.15/1000mm
    Accuracyg6 grade h7 gradeHardened layer depth0.8-3mm
    Roundness tolerance

    <=0.01

    APT thickness10um-40um
    Full length tolerance

    <=0.02

    The materiel42CrMo4
    Surface roughness


    Ra 0.2- 0.4


    NSS Testing Standing une-en iso9227:2017(Neutral Salt Spray test)

    · Sal solution: 50 (+/- 5) g/l of NaCl. Water is demineralized and salt purity is 99.5%.
    · Environmental temperature: 35 °C.
    · pH of salt solution is 6.8.
    · Volumen of salt solution is 38.4 ml/day.
    · Density of salt solution is 1,030 g/cm3.
    · Spraying is 1.5 (+/- 0.5) ml/h.
    Test Result :NSS can endure 300 hours ;500 hours; 800 hours

    TUV NSS Testing Report SGS NSS Testing Report


    Crafts Process Hardening Force Remove

    In the whole crafts process, there are 2 times remove hardening forces: the first remove hardening force in the heat treatment process, hardening force remove is about 80%; the second remove hardening force in the surface treatment process, hardening force remove is about 90%-95%. Therefore, the piston rod is not easily deformed during use or transportation.

    CHEMICAL COMPOSITION
    MaterialC%Mn%Si%S%P%V%Cr%
    Ck450.42-0.500.50-0.800.040.0350.035
    ST520.221.60.550.0350.04
    20MnV60.16-0.221.30-1.700.10-0.500.0350.0350.10-0.20
    42CrMo40.38-0.450.60-0.900.15-0.400.030.030.90-1.20
    40Cr0.37-0.450.50-0.800.17-0.370.80-1.10

    MECHANCIAL PROPERTIES

    MaterialT.S N/MM2Y.S N/MM2E%(MIN)CHARPYCONDITION
    CK4561035515>41JNORMALIZE
    CK4580063020>41JQ + T
    ST5250035522NORMALIZE
    20MnV675059012>40JNORMALIZE
    42CrMo498085014>47JQ + T
    40Cr100080010Q + T
