Industrial Double Acting Telescopic Hydraulic Cylinder Piston
Stroke 600 mm
A double action hydraulic cylinder can move along the horizontal
(x-axis) plane, the vertical (y-axis) plane or along any other
plane of motion. This design uses pressurized hydraulic fluid to
extend and retract the piston rod. This requires fluid ports at
both ends of the actuator in order for the oil to be directed onto
both sides to the piston.
| HSG series hydraulic cylinder |
| models | capacity (ton) | stroke (mm) | bore (mm) | the diameter of rod (mm) | pressure (MPa) | push (KN) | tension (KN) |
| HSGK01-160/90E-131 | 3 | 715 | 160 | 90 | 12 | 321.7 | 219.9 |
| HSGL01-100/60E-131 | 34 | 1200 | 100 | 60 | 23 | 125.66 | 87.65 |
| HSGK01-80/50E-131 | 45 | 700 | 80 | 50 | 12 | 101.79 | 70.37 |
| HSGK01-80/50E-131 | 23 | 640 | 80 | 50 | 10 | 101.79 | 70.37 |
| HSGK01-80/50/E-131 | 12 | 550 | 80 | 50 | 11 | 101.79 | 70.73 |
| HSGL01-80/50-131 | 43 | 500 | 80 | 50 | 14 | 80.43 | 54.98 |
| HSGL01-80/50E-131 | 54 | 440 | 80 | 50 | 15 | 80.43 | 43.41 |
| HSGL01-63/35E-131 | 21 | 200 | 63 | 35 | 16 | 50 | 34.5 |
| HSGL01-63/35E-131 | 12 | 300 | 63 | 35 | 17 | 50 | 34.5 |
| HSGL01-50/28E-131 | 32 | 140 | 50 | 28 | 18 | 31.42 | 21.56 |
| Introduction | Heavy duty hydraulic cylinder HSG series double acting single
piston rod hydraulic cylinder, according to the use function is
divided into : steering cylinder, boom cylinder, lifting cylinder,
tilt cylinder and quick change cylinder, has the characteristics of
connecting mode diversification and buffer device etc..
|
Application of HSG hydraulic cylinder:
Hydraulic cylinder series available
1.Engineering oil cylinder series;
2.Metallurgy oil cylinder series;
3.Turn over plow oil cylinder series;
4.Reaper oil cylinder series;
5.Excavator oil cylinder series;
6. Lift platform cylider;
Features:
1. Many mounting styles.
2. Several bore sizes and in varying strokes.
3. Cylinders are designed for normal or high operating pressures.
4. Many of these sizes are available for immediate delivery.
5. The operating temperature (oil and ambient) is -30 to +80
degrees Celsius, but the unit should not be used when oil is
frozen.
6. Stronger weather resistance: The application new materials and
special structures can adapt to different environment from cold to
hot and can round-clock operation.
7. Rigid welded construction, high tensile welded steel end mounts,
threaded gland and quality seals allow industrial cylinders to work
in harsh conditions.
8. Speed range: Speed range of operation (excluding cushion parts)
is less than 200mm/s. In accordance with customer requirements, the
maker can also supply other ranges of speed.
9. Warranty: We offer 12 months warranty.
About piston rod:
High strength damage resistant piston rod provides 100,000 PSI
minimum yield material in 1" through 4 1/2" diameters. Larger
diameters vary between 50,000 and 75,000 PSI minimum yield
material. All rods are case hardened to 50-55 RC and hard chrome
plated to provide maximum wear life. Stainless steel is also
available. The hard chrome plated of the piston rod according to
your requirement.
Quality control:
1. Seiko secret agents, to ensure quality of the piston rod.
2. The product have to go through heat treatment - bore boring -
grinding - car processing - black nitriding and many other
processes.
3. The company accepted the Valet processing various types and
various sizes products, processing and processing more quotes,
welcome to consult.
Tips:
We offer OEM, ODM. If you needed, please feel free to contact us
and send us the drawings:
| A. The drawing details are as follows. |
| Bore size | Stroke length
|
| Rod diameter | Mounting type
|
| Mounting length | Paint color requirement
|
B. The product application description details |
| 1. Type of machine(loader, steer loader, excavator, and etc.) |
2. Type of function(hoist, swing, steering, and etc.) 3. Type of structure(piston, telescopic) |
| 4. Single or double acting |
| 5. Operating pressure |
