Name: 2 Way Double Acting Hydraulic Cylinder Chrome 100 ton Large Building Bridge
Brand: DALLAST
Price: 1 USD

Add to Cart

2 Way Chrome 100 ton Large Building Bridge Double Acting Hydraulic Cylinder

Application: Heavy duty mining, metallurgy, forging, casting, engineering transportation, hydraulic machinery, food processing machinery, machine tools, civil engineering, construction machinery, chemical machinery, medical machinery, injection molding machinery, automated assembly line, Light industry machinery.
Model	Tonnage (Ton)	ID (mm)	OD (mm)	Rod Diameter (mm)	Sroke (mm)	Body Height (mm)	Stretch Height (mm)	Pressure (Mpa)	Weight (kg)
QF50-100	50	100	140	70	100	265	390	63	27
QF50-160	50	100	140	70	160	300	460	63	30
QF50-200	50	100	140	70	200	340	540	63	34
QF100-100	100	140	180	100	100	300	425	63	49
QF100-160	100	140	180	100	160	335	495	63	54
QF100-200	100	140	180	100	200	375	575	63	60
QF150-100	150	180	245	125	100	310	435	63	90
QF150-200	150	180	245	125	160	345	505	63	106
QF150-250	150	180	245	125	200	385	585	63	120
QF200-100	200	200	273	150	100	325	450	63	120
QF200-160	200	200	273	150	160	360	520	63	130
QF200-200	200	200	273	150	200	400	600	63	145
QF320-200	320	250	325	180	200	410	610	63	205
QF400-200	400	280	377	200	200	440	640	63	310
QF500-200	500	320	426	250	200	460	660	63	436
QF630-200	630	360	490	280	200	517	717	63	693
QF800-200	800	400	550	320	200	567	767	63	974
QF1000-200	1000	450	610	360	200	620	820	63	1337
QF1200-200	1200	500	670	380	200	640	840	63	1647
Program before delivery: 1. Trial Operation Test 2. Start-up Pressure Test 3. Pressure-Tight Test 4. Leak Test 5. Full Stroke Test 6. Buffer Test 7. Testing the Effect of Limit 8. Load Efficiency Test 9. Reliability Test
Every piece of hydraulic cylinder are tested and will send out only after they are pasted the each test
